| Internals |
| Voltage |
120V / 120V–277V |
| Wattage |
MR16 (3W, 5W, 7W) · PAR20 (8W) · PAR30 (10W) ·
PAR38 (15W)
|
| LED |
PAR20: L140 (120–277V), L142 (120–277V), L144 (120V), L146
(120V)
PAR30: L148 (120–277V), L150 (120–277V), L152 (120V), L154
(120V)
PAR38: L156 (120–277V), L158 (120–277V), L162 (120V), L164
(120V)
MR16 Super Saver LED: L106, L108, L110, L114, L116, L118, L119, L124,
L126, L128 (120V)
|
| Lumens |
3W MR16: 270lm · 5W MR16: 450lm · 7W MR16: 550lm ·
PAR20: 600lm · PAR30: 1000lm · PAR38: 1350lm
|
| CCT |
MR16 (3W, 5W, 7W): 2700K · PAR20: 3000K · PAR30: 3000K
· PAR38: 3000K
|
| Wiring |
120V: 48" 18AWG black, white, and green (ground)
120V–277V: 48" 18AWG black, white, and green (ground)
|
| Gasket |
Close cell sponge, 4.75" square x 0.190" thick, center cut out, 2 holes,
PSA 1-side
|
| Socket |
E26 medium base (PAR versions only) · GU10 (MR16 versions
only)
Stationary socket accepts up to a PAR38 bulb.
|
| Bracket |
Medium base 120V adjustable aiming bracket assembly
Aiming bracket accepts PAR20 or PAR30 only — not compatible
with PAR38.
PAR20 gimbals 30° · PAR30 gimbals 15°.
|
| Externals |
| Bucket |
Composite BMC bronze well light bucket |
| Materials |
Aluminum, Brass, Composite |
| Lens |
Convex glass lens, clear tempered, 155mm x 28mm, ±0.5mm
|
| Finish |
Aluminum: Standard finishes (BLT/BRT: Black or Bronze texture); more
finishes available
Brass: Standard unfinished (acid treatments available)
|
| Listings |
IP65. Indoor/Outdoor use. Suitable for wet locations.
|
