24V DC NeonFlex Pro-V Series Custom Cut RGBW Top Bend Strip Light, Dimmable IP67 Light Strip - NFPROV-RGBW-CC

Main Product Image
product detail banner

24V DC NeonFlex Pro-V Series Custom Cut RGBW Top Bend Strip Light, Dimmable IP67 Light Strip - NFPROV-RGBW-CC

SKU:
NFPROV-RGBW-CC
BRAND:
American Lighting
Weight:
5.00 LBS
Color::
RGBW
Type::
Custom Length
Voltage::
24V
$107.92
product detail banner mobile

Designed with the flexibility and precision, the NeonFlex Pro-V RGBW Strip Light will surely elevate your lighting design. Offered in custom lengths up to 16.4 feet, you can match your architectural needs effortlessly. With each custom cut assembly equipped with your choice of power feed and an end cap, this versatile strip light combines cutting-edge technology with user-centric features. From intricate interior design to expansive outdoor applications, the NeonFlex Pro-V provides seamless, bright illumination tailored just for your space. Harness the power of personalization and let your visionay designs come to life with lighting suited to your requirements, ensuring no detail is overlooked.

Versatile Installation

Versatile Installation

Adapt your lighting needs with front, side, and bottom power feeds, ensuring quick and flexible installations anywhere.

High Performance

High Performance

Achieve up to 134 lumens per foot with a consumption of just 4.57W per foot, blending efficiency with power.

Enhanced Durability

Enhanced Durability

Built to withstand challenging conditions, featuring UV, flame, and saltwater resistance, with an IP67 rating.

Smooth Dimming

Smooth Dimming

Fully dimmable from 0-100% using most DMX controls, tailor your lighting to fit any mood or setting.


NeonFlex PRO-V Custom Cut Order Assembly

Each Custom Cut Order of NeonFlex Pro-V RGBW comes pre-assembled with your choice of power feed (front / bottom / left / right) and end cap.

NeonFlex Pro-V Custom Cut RGBW Assembly Diagram
Voltage 24V DC
Wattage 4.57W / ft
Lumens Up to 134Lm / ft
CCT Options RGBW (3000K)
Max Run 16.4ft (5m)
Cutting Points 2.46” (62.5mm)
IP Rating IP67 - Jacketed
Dimming (0-100%) Via DMX Controls
Dimensions 0.63” (16mm) W x 0.59” (20mm) H
Beam Angle 120°
Storage Temp -25ËšC to 60ËšC
Ambient Temp -25ËšC to 45ËšC
Operating Temp -25ËšC to 45ËšC
Certifications cULus Listed - Wet Location
Specification Sheet Download
Instruction Sheet Download

Driver Spec Sheets


30W / 60W / 96W Spec Sheet
200W Spec Sheet
300W Spec Sheet

Product Dimensions


Product Dimensions
